Linear shape LHB series

Linear series 200W high bay

Category:LED High bay Lighting > Linear shape LHB series
Model:GHB200-L1201

Input Voltage (V): AC100-277V

Lamp Power (W): 200W

Lamp Luminous Flux (lm): 24000

Lamp Luminous Efficiency (lm/w): 120~150

CRI (Ra>): 80

Working Temperature (℃) : -40 - +45

Ingress protect : IP65

Certification: CE/ROHS/UL

Inquiry
  • Specifications
  • Dimension
  • Package
  • Installation
  • Replacement

Key features

Perfect replacement for high bay/high ceiling fixture, up to 1000W

 Easy installation and maintenance, less labor cost

 High quality isolated driver inside, more stable and safe

High luminous efficiency to save more energy, max 150lm/w

100% flicker free, protect your eyes from hurt, widely usage

Optional optical lens can be 60°, 9, 30° x 70°, 60° x 90° etc, more decorative



Datasheet

Model Number

 GHB200-L1201

 Replacement

 400W

 Rated Power

 200W

 Luminous Flux

 24000lm

 Input Voltage

 AC100~277V 50/60 Hz

 Installation

 Hanging

 Driver

 Internal driver

 CRI

 82Ra

 Color Temperature

 2700K~6500K optional

 Beam angle

 Optional

 Power Factor

 >0.9

 Life Spam

 50,000 Hours

 Warranty

 3 Years

 Protection Grade

 IP65

 Dimension

 1154*115*144mm

 Material

 Heat Sink: Aluminum, Cover: PC lens

 Series products

 50W,100W,150W,200W,250W,300W,400W,500W



Multiple light distribution for option



  Application area

  Retrofit workshop, factory building, warehouse, gas station, parking lot, car shop

  basketball court, badminton court, sport court, supermarket, stadium, highway toll station etc.
